Articulated Fuel and
Lube Trucks
Ground Force Articulated Fuel and Lube Bodies are purpose-built to withstand the toughest conditions while ensuring operator safety and efficiency through ground-level service points and smartly engineered layouts.
Beyond supply, FMS provides comprehensive servicing and support, ensuring your equipment performs reliably throughout its lifecycle. We also stock and supply the full range of genuine parts, giving you confidence in performance, safety, and long-term value.
Capacity
25 – 45 ton (23 – 41 metric ton)
Discover the
Benefits
INCREASED MANEUVERABILITY AND VERSATILITY:
Ideal for navigating off-road applications in challenging terrains. The lighter weight prevents sinking in muddy or wet terrain. Adaptable for multiple product configurations.
INCREASED EFFICIENCY:
Designed to carry substantial loads with reduced fuel consumption. Fast ground level servicing streamlines maintenance tasks.
LOCAL DEALER SUPPORT:
Supported by FMS Group service expertise and a complete supply of genuine parts for maximum reliability and uptime.
TANK SPECIFICATIONS
| Diesel capacity 2,000 – 5,000 gal (7,570 – 18,927 L) | New oil and coolant capacity: 500 – 1,500 gal (1,892 – 5,678 L) | Grease bin system with optional barrel or removable bin | Spring, hydraulic, and electric reel options | Enclosed and heated body for arctic applications |
| Used oil and coolant tanks | Air compressor with reservoir tank | Systems powered by chassis hydraulics or diesel-driven Auxiliary Power Unit (APU) | Kidney-loop filtration systems |
Roll-over protection system |
| Optional Ground Force chassis frame-stretch | Optional heated product tanks | Optional high-pressure wash system |
OPEN DECK FUEL & LUBE TRUCKS / ENCLOSED FUEL & LUBE TRUCKS
(Arctic Applications)
| Class | Capacity | Model |
|---|---|---|
| 25 T (23 mt) |
Diesel: 2,500 gal. (9,463 L) Lubricants: 930 gal. (3,520 L) Grease: 750 lb. (340 kg) |
25FL/25 EFL |
| 30 T (28 mt) |
Diesel: 3,500 gal. (13,248 L) Lubricants: 1,200 gal. (4,542 L) Grease: 750 lb. (340 kg) |
30FL/30 EFL |
| 35 T (32 mt) |
Diesel: 4,000 gal. (15,141 L) Lubricants: 1,500 gal. (5,678 L) Grease: 1,100 lb. (498 kg) |
35FL/35 EFL |
| 40 T (39 mt) |
Diesel: 5,000 gal. (18,927 L) Lubricants: 1,500 gal. (5,678 L) Grease: 1,100 lb. (498 kg) |
40FL/40 EFL |
| 45 T (41 mt) |
Diesel: 5,000 gal. (18,927 L) Lubricants: 1,500 gal. (5,678 L) Grease: 1,100 lb. (498 kg) |
45FL/45 EFL |
*Capacities may vary depending on chassis size, weight distribution, and custom requirements. All Ground Force Worldwide trucks offer a variety of options and upgrades, all available on most models. All articulated fuel and lube models are available in open deck or enclosed deck for arctic-type applications, as outlined above.
ENHANCE OPERATOR EASE AND SAFETY
| Fuel Delivery: 120-300 GPM (454-1,135 LPM) | Full Product Filtration | Fully Baffled Product Tanks |
| Product Metering Systems | Product Tank Level Gauges | FMS Group Service & Guidance Available |
Get more details – contact FMS Group today.
