Rock Spreaders
FMS Group partners with Ground Force to deliver Rock Spreader Bodies that streamline haul road maintenance by reducing equipment needs, lowering operating costs, and improving efficiency on even the toughest roads. Designed with robust components and advanced in-cab controls, these units ensure safe, precise material delivery across steep grades and challenging conditions.
Backed by FMS Group, you’ll have access to complete servicing and a full supply of genuine parts, keeping your Rock Spreader performing at its best and delivering long-term value to your operation.
Truck Class
60 – 240 ton (55 – 217 metric ton)
Discover the
Benefits
COST SAVINGS:
Reducing costs for maintenance and labor over traditional methods by eliminating the need for multiple operators and additional equipment.
INCREASED EFFICIENCY:
Complete coverage in a single pass, lowering labor costs, reducing tire wear and saving on fuel costs.
INTERCHANGEABILITY:
These bodies are designed for interchangeability with the Ground Force Water bodies. With plug-and-play connections, switching from road maintenance to water season has never been easier.
LOCAL DEALER SUPPORT:
Supported by FMS Group service expertise and a complete supply of genuine parts for maximum reliability and uptime.
SPECIAL FEATURES
| Innovative slope design for smooth material flow | Heavy-duty, extreme service vibrators for ensure efficient material flow | Hydraulically-operated feed gates with sensors for adjustable feed rate | Left and right material discharge dispensers feature | Hydraulic functions utilise the host chassis existing hoist circuit |
| Bed installation utilises host chassis rear pin bosses | Rear bed pin bosses fully welded & line-bored | Sub-frames include shim-style/replaceable body pads | Optional hydraulically operated grizzly screens |
| Class | Rock Spreader Payload | Bed Volume (yd^3) | Model |
|---|---|---|---|
| 60T (55 mt) | 40 tons | 30 (23 cu m) | 60RS |
| 70T (63 mt) | 40 tons | 30 (23 cu m) | 70RS |
| 100T (134 mt) | 67 tons | 50 (38 cu m) | 100RS |
| 150T (136 mt) | 133 tons | 100 (76 cu m) | 150RS |
| 200T (177 mt) | 166tons | 125 (95 cu m) | 200RS |
| 240T (227 mt) | 200 tons | 150 (114 cu m) | 240RS |
*Capacities may vary depending on custom requirements and material density. All Ground Force Worldwide Rock Spreader Trucks offer a variety of options and upgrades.
ENHANCE OPERATOR EASE AND SAFETY
| Ground Force Rock Spreader Control System (RCS) | Inclinometer installed to indicate chute gate position | Easy to operate in-cab display with (6) programable presets | Supplied rear pins with grease zerks |
| Steel cab canopy and top-mounted side spill guards | Removable body for easy change-over to GFW Water Tank kit | Stand for seasonal storage | (4) LED Floodlights to illuminate discharge points |
| Four (4) amber strobe warning light | Back up alarm | FMS Group Field Service available |
Get more details – contact FMS Group today.
